1000ml PE Composite Film Sachet Liquid Filling Machine GMP Standard
Product Details:
| Place of Origin: | Zhangjiagang, China |
| Brand Name: | FillPack |
| Certification: | CE / ISO9001 |
| Model Number: | 1000A1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 1365-2520USD/set |
| Packaging Details: | sea worthy packing |
| Delivery Time: | 25 Working Days After Deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 20 Sets Per Months |
|
Detail Information |
|||
| Model: | 1000A1 | Bag Length: | 50-250MM |
|---|---|---|---|
| Bag Width: | 40-175MM | Packaging Film Width: | 100-380MM |
| Package Volume: | 0-1000ML | Packing Speed: | 1100-1300BAGS PER HOUR |
| Power: | 2.5KW | External Dimensions: | 1050*850*2050MM |
| Highlight: | PE sachet liquid filling machine,1000ml sachet liquid filling machine,PE composite sachet water machine |
||
Product Description
automatic PE composite film sachet liquid drinking water filling packing sealing machine for 0-1000ml bags
Features:
1. The whole process is completed automatically and highly efficient.
2. Either under set length control or photoelectric color tracing, bag length is set and cut in one step.
3. The temperature is under independent PID control, more suitable for different packing materials, the tolerance is ±1%.
4. Equip easy tear-off gap device, so there is an easy tear-off gap on each finished product.
5. The driving system is simple and reliable, and maintenance is easy.
6. Main parts are made of stainless steel, meet the GMP standard.
7. Automatic self support lubricating system, the machine can continuous more than 24 hours.
8. Applicable material should be composite film like: PET/PE, Paper/PE, PET/AL (PET-AL), PE, OPP/PE etc.
1. The whole process is completed automatically and highly efficient.
2. Either under set length control or photoelectric color tracing, bag length is set and cut in one step.
3. The temperature is under independent PID control, more suitable for different packing materials, the tolerance is ±1%.
4. Equip easy tear-off gap device, so there is an easy tear-off gap on each finished product.
5. The driving system is simple and reliable, and maintenance is easy.
6. Main parts are made of stainless steel, meet the GMP standard.
7. Automatic self support lubricating system, the machine can continuous more than 24 hours.
8. Applicable material should be composite film like: PET/PE, Paper/PE, PET/AL (PET-AL), PE, OPP/PE etc.
Model list and technical specifications for different models:
|
Model
|
500A1 |
1000A1
|
500A-2
|
|
Bag length (mm)
|
50-150
|
50-250
|
50-150 |
|
Bag width (mm)
|
40-150
|
40-175
|
40-150
|
|
Packaging film width (mm)
|
100-320
|
100-380
|
100-320
|
|
Package volume (ml)
|
0-500
|
0-1000
|
0-500
|
|
Packing speed (bags/h)
|
2000-2200
|
1100-1300
|
2000-2200
|
|
Power (kw)
|
1.6
|
2.5
|
1.6
|
|
External dimensions (mm)
|
880*760*1800
|
1050*850*2050
|
850*760*1800
|
|
Weight (kg)
|
275
|
380
|
275
|
General:
1, Application: all kinds of liquid without gas, especially soy, wine, vinegar, juice, fruit pulp, soybean milk, peanut oil, vegetable oil, plant oil, mineral water, and liquid chemical products.
2, Sealing style: back sealing
3, Function: film sterilization,auto complete Bag-making, filling, sealing, printing, cutting and counting
4, Whole machine with stainless steel covering, With foot wheels for easy transportation;
Struction design:
Packaging film parameters:
| 1.1.1 | Ribbon date coding |
| 1.1.2 | PE plastic liquid packing film (MOQ:500kg) |
| 1.1.3 | Film mold fee |
| 2.1 | Different voltage customization fee |
We can also provide matching water treatment lines as below picture:
