One / Single Head Adhesive Sticker Labeling / Labeler Machine / Equipment / Line / Plant / System / Unit
Product Details:
| Place of Origin: | ZhangJiaGang,JiangSu,China |
| Brand Name: | Fill Pack |
| Certification: | CE,ISO |
| Model Number: | T-751 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD$3500-5500/set for glass bottle labeling machine |
| Packaging Details: | sea worthy packing |
| Delivery Time: | 5 - 15days |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 15 sets/month |
|
Detail Information |
|||
| Applicable Product: | Width≥20mm，length≥20mm，20≤height≤350mm | Dimension: | 1600*1200*1500mm |
|---|---|---|---|
| Power: | 2kw | Weight: | 195Kg |
| Highlight: | industrial labeling systems,automatic labeling machine |
||
Product Description
Description of Round bottle Single side adhesive labeling machine
>>>Functional characteristics:
★ Adopting a rigid plastic double sided synchronous oriented chain, automatically guarantee the bottle in center, low requirement on workers ' correct putting position, greatly reducing the difficulties of the workers ' jobs for lining and docking. The machine can work separately or work on assembly line.
★ Configuration of the flick-pressure top control mechanism, ensure the transmission of products smoothly and effectively, eliminate the error of bottle height itself.
★ Configure automatic bottle separating device, sparing the distance automatically before bottle guiding, guarantee the stability of the bottle guiding, transmission and labeling.
★ Configure 2 label pressing device , first ensure labeling accuracy, second applying roller system, effectively eliminate air bubbles and guarantee label sides close with bottles tightly.
★ No bottle no labeling, automatic correction for no tag and automatic test function for label, and avoid waste of labels and labeling missing.
★ Strong and healthy, made of stainless steel and high quality alloy, meet the standard with GMP production specifications, reasonable structure, elegant
>>>Basic using:
＊ Core work principle: When sensor detects the products through, it returns the signal to the label control systems, then control system controls control motor to send out the labels and affixed on the product in the right position. Products flow through the label pressing device, label is covered on the products, then completes the labeling action.
＊ Operation procedure: Put the product (on line)-> product delivery (device achieves automatically)-> labeling (device achieves automatically)-> collection of labeling products.
|
No
|
Item
|
Parameter
|
|
1
|
Applicable Label width
|
15≤width≤150mm,length≥10mm
|
|
2
|
Applicable Product size (for round bottle):
|
Width≥20mm,length≥20mm,20≤height≤350mm
|
|
3
|
Labeling accuracy (mm)
|
±1mm (Do not contain the tolerance of product and label itself)
|
|
4
|
Labeling speed (pcs / min)
|
40～180 b/min(Associated with the product)
|
|
5
|
Weight (kg)
|
195Kg
|
|
6
|
Voltage
|
220V 50/60HZ
|
|
7
|
Device dimensions (mm) (L × W × H)
|
1600×1200×1500mm
|
|
If you need shrink sleeve labeling machine, cold glue labeling machine or OPP hot glue labeling machine, please check them on our website or contact the sales consultant directly.
Please find the contact information at contact us.
|
||
Want to Know more details about this product
