Double Sided Sticker Labeling Machine For Glass Beer Bottle Accuracy +/- 1mm
Product Details:
| Place of Origin: | ZhangJiaGang city,JiangSu province of China |
| Brand Name: | Fill Pack |
| Certification: | CE,ISO |
| Model Number: | TB 630-3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set for bottle sticker labeling machine |
|---|---|
| Price: | USD$12,000-14,000/set |
| Packaging Details: | wooden case packing |
| Delivery Time: | 5-15days |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 15 sets/month |
|
Detail Information |
|||
| Main Material: | Stainless Steel 304, Aluminum Alloy 6061 | Dimension: | L 3000mm * W 1500mm * H 1800mm |
|---|---|---|---|
| Voltage: | 220V/50Hz | Power: | 1300 W |
| Production Capacity: | 0-40m/min | Labeling Accuracy: | +/- 1mm Beak Edge |
| Label Roll Core: | 76 Mm | ||
| Highlight: | industrial labeling systems,automatic labeling machine |
||
Product Description
PLC control good quaiity bottle sticker labeling machine for beer glass bottle
Product Description
This bottle sticker labeling machine is suitable for double-sided and bottleneck 3 side labeling. Applies to label roll core 76mm, label diameter of 350mm sticker roll. Applicable label length: 20 ~ 360 mm; Applicable label width: 10 ~ 110 mm (can be customized) Applicable bottle height: 30 ~ 200 mm; Bottle diameter: 30 ~ 90 mm.The main structure of the transmission device transmission, sub-bottle device, the standard device, the standard device and the rack of five parts.
.
Detailed Images
Function:
- Large touch screen, the operation is convenient, the parameter display be clear at a glance, truly realize the man-machine dialogue.
- Adopt German Siemens PLC control system,a more stable performance.
- Adopt Japanese Panasonic photoelectric sensor,higher sensitivity for checking object.
- The horizontal, vertical, can adjust direction labeling position
- Set up in your company existing transport, it also can use online.
- No bottle,not feeding label.
- Large control box, internal electric heat dissipation easier, detection is convenient, being increased
- Stainless steel and aluminum alloy material.
- Aluminum alloy surface by anodize painting, higher strength, good appearance.
- Feeding label buffer device, Ensure that the process of tags do not be pulled apart or cause drag mark.
Technical parameter for bottle sticker labeling machine:
| No | Item | Parameter |
| 1 | Main Material | Stainless Steel 304, Aluminum Alloy 6061 |
| 2 | Dimension | L 3000mm * W 1500mm * H 1800mm |
| 3 | Voltage | 220V/50Hz |
| 4 | Power | 1300 W |
| 5 | Production Capacity | 0-40m/min |
| 6 | Labeling Accuracy | +/- 1mm beak edge |
| 7 | Label Roll Core | 76 mm |
| 8 | Label Roll Diameter | 350 mm |
| 9 | Label Width | 10~110 mm (special size can be customized) |
| 10 | Label Length | 20~360 mm (special size can be customized) |
| 11 | Bottle Diameter | 30~90 mm (special size can be customized) |
| 12 | Bottle Height | 30~200 mm (special size can be customized) |
Delivery time:
The bottle sticker labeling machine will be made within 35 working days after the bottle design are confirmed.
Payment:
30％ T/T deposit within five days after the contract is signed against invoice of the seller. The balance of 70％ T/T before shipment.
Wooden case packing:
Warranty
We response for one year warranty for the bottle sticker labeling machine , however, it without any human conduct. And provide one-year free spare part for client. And send engineer to client’s company with client’s provision for flight charge and accommodation. Help install the machine, teaching their staff operate the machine and also, we do have a private school which help our client sending their staff to china, help them training.
please kindly click the play button to watch the video
