SGS 0.35Mpa Automatic Juice Filling Machine Second Pollution Avoiding
Product Details:
| Place of Origin: | China,JiangSu,Zhangjiagang |
| Brand Name: | FillPack |
| Certification: | CE & ISO & TUV & SGS |
| Model Number: | KLCGF24-24-8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case Package |
| Delivery Time: | 30 Working Days After Receiving Your Deposit Payment |
| Payment Terms: | TT & L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 20 sets/month |
|
Detail Information |
|||
| Weight: | 8000-12000 Kg | Dimension(L*W*H): | 3100*2450*2300 Mm |
|---|---|---|---|
| Filling Pressure: | 0.1-0.35Mpa | Automatic Grade: | Automatic |
| Bottle Type: | PET Plastic Bottle | Condition: | New |
| Material: | SUS304 | Filling Precision: | ≤+/-1mm(liquid Level) |
| Processing Types: | Granular Juice Processing Filling Packing | Voltage: | 380V/220V 50HZ |
| Filling Material: | Juice With Paste Granule | Capacity: | 8000-12000BPH |
| Control: | PLC Control With Touch Screen | Suitable Bottle Size: | 0.3-2L PET Bottle |
| Cap Style: | Plastic Screw Cap | Warranty: | 1 Year For Spare Parts |
| Highlight: | 0.35Mpa automatic juice filling machine,SGS automatic juice filling machine,0.35Mpa juice bottle filling machine |
||
Product Description
Plastic bottle granular juice drink filling line KLCGF24-24-8
UHT(sterilizer)
★ UHT sterilizer is used for heating, sterilization, heat preservation and cooling of juice drinks. This equipment is the ideal equipment for prolonging the retention period of materials through sterilization and cooling.
★ With a variety of safety protection measures and high temperature alarm, low temperature reflux function. Materials and heating medium are heated by non-contact heat exchange in their respective sealing systems to ensure the health and safety of materials.
| Washing Filling Capping 3-in-1 in the Granular Juice filling line | |||||
| Model | KLCGF12-12-4 | KLCGF18-18-6 | KLCGF24-24-8 | KLCGF32-32-12 | KLCGF40-40-12 |
| Capacity | 4000BPH | 5000-7000BPH | 8000-12000BPH | 12000-15000BPH | 15000-20000BPH |
| Bottle shape | (Bottle Diameter):50-110mm (Height):160-320mm | ||||
| PET bottle | PET screw | ||||
| Filling precision | ≤+/-1% | ||||
| Filling pressure | 0.15-0.35MPa | 0.15-0.35MPa | 0.15-0.35MPa | 0.15-0.35MPa | 0.15-0.35MPa |
| Rinsing pressure | 0.2-0.25MPa | 0.2-0.25MPa | 0.2-0.25MPa | 0.2-0.25MPa | 0.2-0.25MPa |
| Power | 4.4Kw | 4.4Kw | 5.2Kw | 6.2Kw | 7.8Kw |
| Size(mm) | 2100*1750*2200 | 2800*2150*2300 | 3100*2450*2300 | 3800*2800*2500 | 4100*3000*2500 |
| Weight(Kg) | 3500 | 5000-7000 | 8000-12000 | 12000-15000 | 15000-20000 |
| If you need non-granular juice filling line, please check them on our website or contact the sales consultant directly. | |||||
1, Water treatment system
2, Vacuum degasser
3, Homogenizer
4, Washing Filling Capping Heads
★ The three functions of bottle washing, filling and capping are composed in one body of the machine.
★ The rinsing, filling, capping machine is automatically controlled by PLC.
★ Direct connection technology is used between air conveyor and in-feeding starwheel to substitute in-feeding screw and conveyor. It is easy to change the size of bottles.
★ The head of filling machine is made of better stainless steel, which is firm and endurable.
5, Labeling machine with code printer
6, Film shrinking packing machine
