Bottle / Bottled Drink Tea Apple Orange Beverage Juice Producing Machine / Equipment / Plant / Unit / System / Line
Product Details:
| Place of Origin: | China,JiangSu,Zhangjiagang |
| Brand Name: | FillPack |
| Certification: | CE & ISO & TUV & SGS |
| Model Number: | KLCGF32-32-12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case Package |
| Delivery Time: | 30 Working Days After Receiving Your Deposit Payment |
| Payment Terms: | TT & L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 20 sets/month |
|
Detail Information |
|||
| Weight: | 12000-15000 Kg | Dimension(L*W*H): | 3800*2800*2500 Mm |
|---|---|---|---|
| Filling Pressure: | 0.1-0.35Mpa | Automatic Grade: | Automatic |
| Bottle Type: | PET Plastic Bottle | Condition: | New |
| Material: | SUS304 | Filling Precision: | ≤+/-1mm(liquid Level) |
| Processing Types: | Granular Juice Processing Filling Packing | Voltage: | 380V/220V 50HZ |
| Filling Material: | Juice With Paste Granule | Capacity: | 12000-15000BPH |
| Control: | PLC Control With Touch Screen | Suitable Bottle Size: | 0.3-2L PET Bottle |
| Cap Style: | Plastic Screw Cap | Warranty: | 1 Year For Spare Parts |
| Highlight: | aseptic juice filling machine,high speed filling machine |
||
Product Description
Product Description
Plastic bottle granular juice drink filling line KLCGF32-32-12
Overview of Production Line:
★ The granular juice blending process is designed according to the formula of the juice drink. Usually, the juice blending process is: sugar preparation syrup, syrup filtration, concentrated juice dilution, juice mixing tank,Vacuum degasser, Homogenizer, UHT(Sterilization), CIP cleaning.
★ Drinking Water Treatment Equipment → Syrup pot → Syrup Filter → juice mixing tank → Vacuum degasser → Homogenizer → UHT(Sterilization) → Washing, Filling, Capping 3-in-1 Machine For Filling Juice → Bottle Inverted Conveyor Sterilization → Spray Water Sterilization.(85℃) → Labeling Machine Code printer → Shrink wrap packing machine→ Finished Products
★ Drinking Water Treatment Equipment → Syrup pot → Syrup Filter → juice mixing tank → Vacuum degasser → Homogenizer → UHT(Sterilization) → Washing, Filling, Capping 3-in-1 Machine For Filling Juice → Bottle Inverted Conveyor Sterilization → Spray Water Sterilization.(85℃) → Labeling Machine Code printer → Shrink wrap packing machine→ Finished Products
Granular Juice Processing System
The heating method can be steam heating, sugar melting pot, ingredient tank and beverage heat preservation tank can be made into three layers of heat preservation treatment, the outermost layer is heat preservation cotton, the middle layer is steam layer, and the latter layer is material, so the heating speed is fast, the heat loss is small, and the cost can be greatly reduced, so a steam boiler needs to be configured.
Washing, Filling, Capping 3-in-1 Machine For Filling Juice
This machine is used to produce granular juice for plastic bottle, there is seperate particle filler, which can fill granule pulp or particle, the machine combine rinser, juice filler, granule filler and capper in one unit, suitable to produce granular juice, dairy drink, tea drink, flavor drink, and other non-carbonated drink.
Bottle Inverted Conveyor Sterilization.
1, The inverted bottle sterilization machine is a special equipment for the hot filling production line which is developed according to the process characteristics of the hot filling production line and needs to be developed by itself.
2, The temperature of the whole process is controlled between 65-85℃. When passing through the bottle pouring sterilizer, the bottle will turn 360 degrees. The inverted bottle sterilizer use the high temperature of the product to sterilize the bottle cap in a specified time(28～30second), soften the seal of the cap, and improve the cap and bottle.
1, The inverted bottle sterilization machine is a special equipment for the hot filling production line which is developed according to the process characteristics of the hot filling production line and needs to be developed by itself.
2, The temperature of the whole process is controlled between 65-85℃. When passing through the bottle pouring sterilizer, the bottle will turn 360 degrees. The inverted bottle sterilizer use the high temperature of the product to sterilize the bottle cap in a specified time(28～30second), soften the seal of the cap, and improve the cap and bottle.
| Washing Filling Capping 3-in-1 in the Granular Juice filling line | |||||
| Model | KLCGF12-12-4 | KLCGF18-18-6 | KLCGF24-24-8 | KLCGF32-32-12 | KLCGF40-40-12 |
| Capacity | 4000BPH | 5000-7000BPH | 8000-12000BPH | 12000-15000BPH | 15000-20000BPH |
| Bottle shape | (Bottle Diameter):50-110mm (Height):160-320mm | ||||
| PET bottle | PET screw | ||||
| Filling precision | ≤+/-1% | ||||
| Filling pressure | 0.15-0.35MPa | 0.15-0.35MPa | 0.15-0.35MPa | 0.15-0.35MPa | 0.15-0.35MPa |
| Rinsing pressure | 0.2-0.25MPa | 0.2-0.25MPa | 0.2-0.25MPa | 0.2-0.25MPa | 0.2-0.25MPa |
| Power | 4.4Kw | 4.4Kw | 5.2Kw | 6.2Kw | 7.8Kw |
| Size(mm) | 2100*1750*2200 | 2800*2150*2300 | 3100*2450*2300 | 3800*2800*2500 | 4100*3000*2500 |
| Weight(Kg) | 3500 | 5000-7000 | 8000-12000 | 12000-15000 | 15000-20000 |
| If you need non-granular juice filling line, please check them on our website or contact the sales consultant directly. | |||||
Other machines in the production line
★ Water treatment system
★ Vacuum degasser
★ Homogenizer
★ Labeling machine with code printer
★ Film shrinking packing machine
