5 Gallon Semi Automatic Pet Bottle Manufacturing Machine for capacity 120BPH
Product Details:
| Place of Origin: | ZhangJiaGang,JiangSu,China |
| Brand Name: | FILL PACK |
| Certification: | CE. ISO9001 |
| Model Number: | FP-120 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | USD $12,000-15,000/Set |
| Packaging Details: | the Bottle Blowing Machine is packed by wooden case. |
| Delivery Time: | within 30 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 10 Set/Sets per month |
|
Detail Information |
|||
| Condition: | New | Application: | Bottle |
|---|---|---|---|
| Plastic Processed: | PET | Blow Moulding Type: | Stretch Blow Moulding |
| Automatic: | No | Voltage: | 380V |
| Power(W): | 25kw | Dimension(L*W*H): | 2.2X0.8X2.2M |
| Weight: | 1500kg | Warranty: | 1 Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Output: | 120BPH |
| Material: | Stainless Steel | Suitable Bottle: | 5 Gallon Bottle |
| Highlight: | Bottle Injection Machine,Bottle Making Machine |
||
Product Description
5 Gallon Semi Automatic Pet Bottle Manufacturing Machine for capacity 120BPH
Product Description
Specification:
FP-120 Bottle Blowing Machine Manufacturer is especially used to produce 3 gallon and 5 gallon bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.
● Perfect function with economic investment.
● Small size and compact construction with no space waste.
● Easy to operate and maintain ,operation by one person.
● Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system.
● We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customer's requirements.
|
Name
|
Item
|
Unit
|
Details
|
|
Blowing machine
|
Dimension
|
mm
|
2300*750*2100
|
|
Bottle volume (max)
|
L
|
22
|
|
|
Bottle volume (min)
|
L
|
5
|
|
|
Bottle Neck Diameter (max)
|
mm
|
90
|
|
|
Bottle Neck Diameter (min)
|
mm
|
38
|
|
|
Body Diameter (max)
|
mm
|
300
|
|
|
Body Height( max)
|
mm
|
550
|
|
|
Number of Cavities
|
mold
|
1
|
|
|
Production output
|
pcs/h
|
5GALLON:85-90PCS/HOUR
|
|
|
Clamping force
|
T
|
20(200KN)
|
|
|
Mold thickness
|
mm
|
450(max)
|
|
|
Mold width
|
mm
|
430x530
|
|
|
Space between Tie-bars
|
mm
|
430*470
|
|
|
Diameter of Tie-bars
|
mm
|
63
|
|
|
Scope of Tie-bars
|
mm
|
405
|
|
|
Mold stroke
|
mm
|
170
|
|
|
Stretching stroke (max)
|
mm
|
420
|
|
|
Working pressure
|
Mpa
|
0.8-1.0Mpa
|
|
|
Blowing pressure
|
Mpa
|
2.0-3.0Mpa
|
|
|
Voltage/Power
|
V/KW
|
220V/1KW
|
|
|
Pre-heater
|
Dimension
|
mm
|
2300*750*2100MM
|
|
Weight
|
kg
|
1600
|
|
|
Voltage/Power
|
V/KW
|
380V/28KW
|
|
|
Lamp
|
PCS
|
32
|
|
|
Working power
|
Kw
|
15kw
|
Detailed Images
Packing & Delivery
1. the Bottle Blowing Machine is packed by wooden case.
2. The delivery date of Bottle Blowing Machine is within 30 days after payment.
Our Service
Customer's service:
1. FILL-PACK company can provide turn-key project for you, only you have any idea to start beverage factory plant.
2. FILL-PACK company have professional design team, our engineer can draw bottle samples and flow chart ofworkshop for you .
3. FILL-PACK company give you the best quotation for all kinds of beverage production, only you can tell me which kind of drink you want to product, what is your capacity(how many bottles one hour) what is you bottle material, pet or glass,etc
After service:
1. We send the engineers to help installing, commissioning and training, the engineers start from our factory area.
2. We supply below necessary documents with the machine:
a. Machine layout
b. Electricity diagram
c. Machine certificate
d. General manual book/maintenance book
3. After one year guarantee, the seller provides payable spare parts and technician’s VISITING maintenance service.
