SUS304 Single Head 1000ml Volumetric Piston Filling Machine
Product Details:
| Place of Origin: | ZhangJiaGang City, JiangSu Province, China |
| Brand Name: | FILL PACK |
| Model Number: | QDG-2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD315-820 /unit |
| Packaging Details: | Sea worthy package |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 50 sets/month |
|
Detail Information |
|||
| Model: | Single Head Liquid Filling Machine | Voltage: | AC220/110V 50/60HZ |
|---|---|---|---|
| Power: | 20W | Air Pressure: | 0.4-0.6mpa |
| Filling Speed: | 5-25BPM | Filling Precision: | ≤±1% |
| Material: | SUS304 | Filling Range Options: | 3-30ml; 10-100ml; 30-300ml; 50-500ml; 100-1000ml; 500-3000ml; 1000-5000ml |
| Highlight: | 1000ml volumetric piston filling machine,SUS304 volumetric piston filling machine,Single head piston bottle filler |
||
Product Description
100ml-1000ml Semi auto pneumatic paste filling machine for cream / Honey / Sauce / shampoo
viscosity filling machine Usage:
The pneumatic cream filling machine is used to filling food industry such as jam, meat sauce,It can be used to filling for all kinds of paste.
Pneumatic viscosity filling machine Principle:
The pneumatic cream filling machine adopts pneumatic working principle, simple operation, high filling precision, is a certain concentration or certain size granular materials ideal filling equipment.
The machine is equipped with foot switch, it can stop working at any time.
Remark:
The pneumatic cream filling machine has round and square hopper, can be customized as customer’s requirements.
Pneumatic viscosity filling machine parameteres:
|
Model
|
Single head viscosity filling machine
|
Double heads viscosity filling machine
|
|
Voltage
|
AC220/110V 50/60HZ
|
|
|
Power
|
20W
|
50W
|
|
Air pressure
|
0.4-0.6mpa
|
|
|
Filling speed
|
5-25BPM
|
10-50BPM
|
|
Filling precision
|
≤±1%
|
|
|
Material
|
SUS304
|
|
|
Filling range options
|
3-30ml; 10-100ml; 30-300ml; 50-500ml; 100-1000ml; 500-3000ml; 1000-5000ml
|
|
|
Air consumption
|
≥0.008m³/second
|
|
